Remeha RSC 150 Plus spare parts

In brief

Instalpunt supplies 49 original parts for the Remeha RSC 150 Plus, including gas valves and gas control, PCBs and controls, burners. Order online.

49Spare parts
2In stock
€2.94From
12Types
availableExploded view

Looking for parts for the Remeha RSC 150 Plus (hot water cylinder)? Below are all 49 original parts, grouped by part type, with the matching exploded view. Choose a type to jump straight to the right table.

View the interactive exploded view →

Gas valves and gas control 1
PCBs and controls 1
Burners 2
Displays and controls 1
Anodes 1
Electrical parts 4
Cables and wiring harnesses 6
Gasket sets 1
Gaskets and seals 1
Pipes, tubes and hoses 4
Casing and panels 4
Fixing material 9
Other parts 14

Gas valves and gas control for the Remeha RSC 150 Plus (1) all Remeha gas valves and gas control →

Part	Item no. / mfr. no.	Price	Stock
Remeha gas valve for e.g. RSC 150 Plus 7709916	80101292 Mfr. no. 7709916	€687.95	Made-to-order item	View & order

PCBs and controls for the Remeha RSC 150 Plus (1) all Remeha PCBs and controls →

Part	Item no. / mfr. no.	Price	Stock
Remeha PCB for e.g. RSC 150 Plus 7709731	80101275 Mfr. no. 7709731	€463.95	In stock	View & order

Burners for the Remeha RSC 150 Plus (2) all Remeha burners →

Part	Item no. / mfr. no.	Price	Stock
Remeha burner for e.g. RSC 150 Plus 7709715	80101274 Mfr. no. 7709715	€509.95	Made-to-order item	View & order
Remeha burner assembly for e.g. RSC 150 Plus 7709913	80101290 Mfr. no. 7709913	€661.95	Made-to-order item	View & order

Displays and controls for the Remeha RSC 150 Plus (1) all Remeha displays and controls →

Part	Item no. / mfr. no.	Price	Stock
Remeha display	80101250 Mfr. no. 7709924	€276.95	Made-to-order item	View & order

Anodes for the Remeha RSC 150 Plus (1) all Remeha anodes →

Part	Item no. / mfr. no.	Price	Stock
Remeha anode with hot water nipple	80101221 Mfr. no. 7709710	€97.95	Made-to-order item	View & order

Electrical parts for the Remeha RSC 150 Plus (4) all Remeha electrical parts →

Part	Item no. / mfr. no.	Price	Stock
Remeha terminal block s4	80101015 Mfr. no. 7709876	€7.95	Made-to-order item	View & order
Remeha capacitor for e.g. RSC 150 Plus 7709841	80101183 Mfr. no. 7709841	€65.95	Made-to-order item	View & order
Remeha transformer 220/24V	80101238 Mfr. no. 7709733	€182.95	Made-to-order item	View & order
Remeha switch box complete	80101300 Mfr. no. 7709896	€1,130.95	Made-to-order item	View & order

Cables and wiring harnesses for the Remeha RSC 150 Plus (6) all Remeha cables and wiring harnesses →

Part	Item no. / mfr. no.	Price	Stock
Remeha cable alarm module for e.g. RSC 150 Plus 7709945	80101123 Mfr. no. 7709945	€26.95	Made-to-order item	View & order
Remeha display cable for e.g. RSC 150 Plus 7709941	80101134 Mfr. no. 7709941	€30.95	Made-to-order item	View & order
Remeha wiring harness for e.g. RSC 150 Plus 7709943	80101142 Mfr. no. 7709943	€48.95	Made-to-order item	View & order
Remeha cable set temperature switch	80101158 Mfr. no. 7709872	€55.95	Made-to-order item	View & order
Remeha cable set gas valve for e.g. RSC 150 Plus 7709867	80101209 Mfr. no. 7709867	€90.95	Made-to-order item	View & order
Remeha cable set sensors	80101216 Mfr. no. 7709939	€100.95	Made-to-order item	View & order

Gasket sets for the Remeha RSC 150 Plus (1) all Remeha gasket sets →

Part	Item no. / mfr. no.	Price	Stock
Remeha gasket set	80101172 Mfr. no. 7709866	€68.95	Made-to-order item	View & order

Gaskets and seals for the Remeha RSC 150 Plus (1) all Remeha gaskets and seals →

Part	Item no. / mfr. no.	Price	Stock
Remeha gasket for e.g. RSC 150 Plus 7709802	80101085 Mfr. no. 7709802	€22.95	Made-to-order item	View & order

Pipes, tubes and hoses for the Remeha RSC 150 Plus (4) all Remeha pipes, tubes and hoses →

Part	Item no. / mfr. no.	Price	Stock
Remeha flue adapter	80101088 Mfr. no. 7709801	€11.95	Made-to-order item	View & order
Remeha union nut	80101108 Mfr. no. 7709800	€24.95	Made-to-order item	View & order
Remeha cold water inlet pipe (RSC/SEN 150 Plus)	80101160 Mfr. no. 7709720	€58.95	Made-to-order item	View & order
Remeha dip tube for e.g. RSC 150 Plus 7709785	80101230 Mfr. no. 7709785	€113.95	Made-to-order item	View & order

Casing and panels for the Remeha RSC 150 Plus (4) all Remeha casing and panels →

Part	Item no. / mfr. no.	Price	Stock
Remeha door for e.g. RSC 150 Plus 7709820	80101149 Mfr. no. 7709820	€45.95	Made-to-order item	View & order
Remeha cover for e.g. RSC 150 Plus 7709824	80101177 Mfr. no. 7709824	€59.95	Made-to-order item	View & order
Remeha control panel back plate	80101189 Mfr. no. 7709823	€68.95	Made-to-order item	View & order
Remeha cover assembly	80101263 Mfr. no. 7709885	€313.95	Made-to-order item	View & order

Fixing material for the Remeha RSC 150 Plus (9) all Remeha fixing material →

Part	Item no. / mfr. no.	Price	Stock
Remeha plastic cap	80101017 Mfr. no. 7709875	€7.95	Made-to-order item	View & order
Remeha plug for e.g. RSC 150 Plus 7709878	80101018 Mfr. no. 7709878	€7.95	Made-to-order item	View & order
Remeha screw 10-12 x 3/4	80101019 Mfr. no. 7709814	€7.95	Made-to-order item	View & order
Remeha screw 6-20 x 3/8	80101021 Mfr. no. 7709813	€7.95	Made-to-order item	View & order
Remeha screw 8-18 x 3/4 for e.g. RSC 150 Plus 7709811	80101022 Mfr. no. 7709811	€7.95	Made-to-order item	View & order
Remeha screw 8-18 x 3/4 for e.g. RSC 150 Plus 7709816	80101023 Mfr. no. 7709816	€7.95	Made-to-order item	View & order
Remeha screw 8-18x1/2	80101025 Mfr. no. 7709810	€7.95	Made-to-order item	View & order
Remeha screw 8-18 x 1/2	80101026 Mfr. no. 7709796	€7.95	Made-to-order item	View & order
Remeha gas valve mounting plate	80101222 Mfr. no. 7709947	€121.95	Made-to-order item	View & order

Other parts for the Remeha RSC 150 Plus (14)

Part	Item no. / mfr. no.	Price	Stock
Remeha ignition burner for e.g. RSC 150 Plus 7709786	80101234 Mfr. no. 7709786	€102.95	In stock	View & order
Remeha on/off switch for e.g. RSC 150 Plus 7709946	80101104 Mfr. no. 7709946	€24.95	Made-to-order item	View & order
Remeha temperature switch	80101107 Mfr. no. 7709807	€26.95	Made-to-order item	View & order
Remeha restriction ring for e.g. RSC 150 Plus 7709792	80101116 Mfr. no. 7709792	€26.95	Made-to-order item	View & order
Remeha damper harness jumper	80101133 Mfr. no. 7709870	€30.95	Made-to-order item	View & order
Remeha inner door for e.g. RSC 150 Plus 7709869	80101153 Mfr. no. 7709869	€54.95	Made-to-order item	View & order
Remeha retarder for e.g. RSC 150 Plus 7709886	80101159 Mfr. no. 7709886	€49.95	Made-to-order item	View & order
Remeha coupling pipe	80101186 Mfr. no. 7709851	€69.95	Made-to-order item	View & order
Remeha flexible gas pipe	80101212 Mfr. no. 7709732	€97.95	Made-to-order item	View & order
Remeha air inlet pipe for e.g. RSC 150 Plus 7709850	80101214 Mfr. no. 7709850	€100.95	Made-to-order item	View & order
Remeha air inlet pipe for e.g. RSC 150 Plus 7709849	80101215 Mfr. no. 7709849	€97.95	Made-to-order item	View & order
Remeha flue gas collector box for e.g. RSC 150 Plus 7709831	80101252 Mfr. no. 7709831	€243.95	Made-to-order item	View & order
Remeha air inlet piece	80101254 Mfr. no. 7709833	€261.95	Made-to-order item	View & order
Remeha flue kit	80101264 Mfr. no. 7709893	€313.95	Made-to-order item	View & order

Exploded views of the Remeha RSC 150 Plus

Click an exploded view to enlarge it. The position numbers are shown next to each part.

Fault code on your Remeha RSC 150 Plus? This is the part type involved

Common Remeha fault codes and the part type that is usually the cause; the parts for this model are listed above. All codes explained: Remeha fault codes.

Code	What is going on	Part type
3	Gas valve defective	Gas valves and gas control
6	Flame detected out of normal sequence (before opening or after closing of the gas valve).	Gas valves and gas control
E 428	The burner control unit is blocked (E_12) and the gas valve is energised. In that case the burner control unit is switched off (E_12 signalling stopped).	Gas valves and gas control
E 429	Presence of u_29 for more than 10 minutes (with burner control unit switched on).	Burners
E 484	Damage to one of the 2 fuses of the 24-0-24 Vac input or break in one of the wires of the 24-0-24 Vac supply to the PCB.	PCBs and controls
E 485	The module type set (in menu 6) does not match the one managed by the PCB.	PCBs and controls

For guidance only: the same code can have a different cause depending on the situation.

Other Remeha hot water cylinders

← All Remeha parts

Frequently asked questions

Which parts are available for the Remeha RSC 150 Plus?

The catalogue lists 49 original parts for the Remeha RSC 150 Plus, including gas valves and gas control, PCBs and controls, burners, displays and controls. All parts are listed above, grouped by type, with part number and price.

How much does a gas valve for the Remeha RSC 150 Plus cost?

The gas valves and gas control for this model cost €922.60 incl. VAT. Check the table "Gas valves and gas control" above for the right part number.

Are the parts for the Remeha RSC 150 Plus in stock?

2 of the 49 parts are in stock; shipping to EU countries from €12.95 (€16.95 for more distant countries), usually 3–5 working days. Parts marked "Made-to-order item" are ordered specially for you; the delivery time is shown on the product page.

How do I know which part I need for the Remeha RSC 150 Plus?

Search for the part by part number or use the exploded view of the Remeha RSC 150 Plus.

Are these original Remeha parts?

Yes. All 49 parts in this list are original manufacturer parts for the Remeha RSC 150 Plus, supplied through the official technical wholesale channel and with the correct part number.

How much do parts for the Remeha RSC 150 Plus cost?

Parts for the Remeha RSC 150 Plus range from €2.94 to €1,411.34 incl. VAT. The exact price of each part is shown in the tables above.

Can I return a part?

As a consumer you have a 14-day right of withdrawal. You may unpack and inspect the part; do not install or connect it. For a part that has been installed, connected or damaged we deduct the diminished value, up to the full price for circuit boards.
